“TERMINATOR XNF29” – 29 PIECE SOLID SUB-MICRON C-2 CARBIDE CGDF-Treated. The best money can buy for Non-Ferrous alloys, Cast Iron, PLASTICS, ALUMINUM and Highly abrasive materials.
Family Owned. Slightly Twisted.
Real people who actually know drill bits pick up the phone.
Fast Shipping Nationwide
Most orders are out the door the same or next business day.
Built for Steel, Not Shelves
Shop-grade bits for people who drill all day and break stuff for a living.
Stumped? Call the Bit Experts.
Tell us the material and the job, and we'll get you the right bit. 800-350-8665.
TERMINATOR XNF29 Sub-Micron Solid Carbide Twist Drill Bit Set – 29 Piece
29-Piece Solid Carbide Drill Bit Set – 1/16″ through 1/2″
Sub-Micron C2 Carbide • Precision Ground • Made in USA
The TERMINATOR XNF29 is a professional 29-piece solid carbide drill bit set built for machinists, toolrooms, production environments, and demanding drilling applications where accuracy, rigidity, and tool life matter.
Made in the USA from premium sub-micron C2 solid carbide, the XNF29 provides exceptional wear resistance, cutting-edge stability, and dimensional accuracy. Each drill is precision ground for clean, consistent hole production and dependable performance in rigid machining setups.
The 4-facet 118° split point provides fast, accurate starts with reduced walking, while the precision-ground flute geometry promotes efficient chip evacuation and smooth cutting performance.
With tight diameter control and the rigidity of solid carbide, these drills are capable of producing reamer-type hole finishes in the proper application while maintaining excellent size consistency and repeatability.
THE ULTIMATE SET TO OWN
Recommended Materials
Excellent for drilling:
Also suitable in the proper machine setup and cutting conditions for:
Set Includes
| Drill Size | LOC | OAL |
|---|---|---|
| 1/16″ | 3/4″ | 1-1/2″ |
| 5/64″ | 7/8″ | 1-3/4″ |
| 3/32″ | 1″ | 2″ |
| 7/64″ | 1-1/4″ | 2-1/4″ |
| 1/8″ | 1-1/4″ | 2-1/4″ |
| 9/64″ | 1-3/8″ | 2-1/2″ |
| 5/32″ | 1-3/8″ | 2-1/2″ |
| 11/64″ | 1-5/8″ | 2-3/4″ |
| 3/16″ | 1-5/8″ | 2-3/4″ |
| 13/64″ | 1-3/4″ | 3″ |
| 7/32″ | 1-3/4″ | 3″ |
| 15/64″ | 2″ | 3-1/4″ |
| 1/4″ | 2″ | 3-1/4″ |
| 17/64″ | 2-1/4″ | 3-1/2″ |
| 9/32″ | 2-1/4″ | 3-1/2″ |
| 19/64″ | 2-3/8″ | 3-3/4″ |
| 5/16″ | 2-3/8″ | 3-3/4″ |
| 21/64″ | 2-1/2″ | 4″ |
| 11/32″ | 2-1/2″ | 4″ |
| 23/64″ | 2-3/4″ | 4-1/4″ |
| 3/8″ | 2-3/4″ | 4-1/4″ |
| 25/64″ | 2-7/8″ | 4-1/2″ |
| 13/32″ | 2-7/8″ | 4-1/2″ |
| 27/64″ | 2-7/8″ | 4-1/2″ |
| 7/16″ | 2-7/8″ | 4-1/2″ |
| 29/64″ | 3″ | 4-3/4″ |
| 15/32″ | 3″ | 4-3/4″ |
| 31/64″ | 3″ | 4-3/4″ |
| 1/2″ | 3″ | 4-3/4″ |
LOC = Length of Cut
OAL = Overall Length
Performance Notes
For maximum tool life, hole quality, and cutting performance:
Made in USA
The TERMINATOR XNF29 is assembled exclusively for DrillBitWarehouse.com using premium USA-made solid carbide drills selected for professional machining and production work.
When accuracy, rigidity, hole quality, and tool life matter, the XNF29 is the carbide set built for the job.
Need Help Choosing the Right Carbide Drill Bit?
Call 800-350-TOOL — that’s what we’re here for.
| Weight | 9.977324263038549 lbs |
|---|---|
| Dimensions | 5 × 2.5 × 8 in |
